| Parameters |
Technical Details |
| Capacity available |
3kva to 750kva |
| Input voltage range |
Standard: 360V-470V & 340-470V |
| Output voltage |
380V / 400V / 415V |
| Output voltage accuracy |
(+/- 1% |
| Cooling Method |
Natural Air cooled & Oil cooled |
| Duty Cycle |
Continous |
| Frequency |
47-53Hz |
| Waveform distortion |
Nil |
| Efficiency |
Better than 97% |
| Environment |
Indoor Application |
| Mounting |
Free on Wheels |
| Protection |
Under/Over voltage cut-off
Short-circuit protection
Overload protection |
| Metering |
Analog Voltmeter
Ampere / Current meter
*for capaci |
| Other features |
Dual mode (Auto/Manual)
True RMS value card for DG set
LED indications Potentiometer
for output voltage adjustment |
| Optional features that can be
availed |
Ampere / Current Meter
Digital Meter
Manual bypass switch
RFI filter
Spike suppressor
True RMS Value sensing card |
